1/4 in. Screw Size HSS Solid Pilot Cap Screw Counterbore - .2810 in. Pilot Dia.
Whitney Cap Screw Counterbores - Inch
Solid Pilot
Made in USA
- Item Code: CBSP04063
- Availability:
- Mfg Part #: 10541
- Brand: Whitney Tool
Unit Size: 1
Features Back To Top
- High Speed Steel
- Weldon Shank
- 3-Flute Rugged Free Cutting Design
Tech Specs Back To Top
| UPC | 648672105410 |
|---|---|
| Decimal Cutting Diameter | 0.4060" |
| Metric Cutting Diameter | 10.3124 mm |
| Pilot Diameter Decimal | 0.2810" |
| Material | High Speed Steel |
| Brand | Whitney Tool |
| Pilot Diameter Tolerance | +0", -0.0005" |
| Shank Diameter | 3/8" |
| Number of Teeth | 3 |
| Shank Diameter Tolerance | +0", -0.0005" |
| Shank Type | Weldon |
| Coating/Finish | None |
| Overall Length (Inch) | 5" |
| OD Tolerance | +0.002", -0" |
| Tooth Configuration | 20 deg. Right Hand Helix |
