10-32 UNF, High Speed Steel, H3 Plug, 2-Flute, Gun Tap

10-32 UNF, High Speed Steel, H3 Plug, 2-Flute, Gun Tap

Series 5301

GUN Taps for Through Holes in General Machining Applications

WIDIA
  • Item Code: 13634
  • Availability:
  • Mfg Part #: 2866726
  • Brand: WIDIA

Unit Size: 1

Features Tech Specs Reviews

Features Back To Top

    • Production Taps
    • Spiral Point
    • Plug Chamfer

Tech Specs Back To Top

Thread Length 0.8750 Inch
Threads Per Inch 32
Diameter #10 - 32
Material HSS
Thread Limit H3
Product Name Tap
Thread Type NF/UNF/UNJF
Chamfer Bottoming
Overall Length 2-3/8 Inch
Shank Diameter 0.1940 Inch
Brand WIDIA
Coating Uncoated
Number of Flutes 2
Unit of Measure Inch
Shank Style Square
Square Size 0.1520 Inch
